INFRASTRUCTURE
We have 3000 sq feet of company shed where we installed 4CNC wire cut EDM machines, VMC and all conventional machineries.
CNC WIRECUT EDM
Mitsubishi MV1200-S (Submersible with FMC) – 2 machines
- Axis travels size X,Y & Z 400mm, 300mm & 220mm
- Tapper angel 15 degree at 200mm
- Wire diameter 0.10mm to 0.30mm
- Surface finish upto 0.27 Ra
- All complex profiles and fine blanking tools can be done.
SUZHOU BAOMA DK-7763 CH (E3)
- Axis travel ( x, y, z Axis) 800x630mm x500mm
- Maximum work piece thickness 500mm
- Maximum Taper ± 3degree /120mm
- Machining Accuracy 0.010mm
- Maximum work piece weight 3000kg
SUZHOU BAOMA DK-7740 CH (E3)
- Axis travel ( x, y Axis) 500x400mm
- Maximum work piece thickness 500mm
- Maximum Taper ± 3degree /120mm
- Machining Accuracy 0.010mm
- Maximum work piece weight 500kg
VMC BFW 60++
- SIEMENS CONTROLL
- Axis Travel 1250 X 600 X600
- Spindle RPM 10,000
- Machine tolerance 0.01
AND ALL CONVENTIONAL MACHINERIES
List OF Measuring Instruments
| NAME | NO'S |
|---|---|
| Digital venire caliper (0 – 150, 0 – 200 & 0 – 300mm) | 3Nos |
| Micro meter Range ( 0 - 250mm step 25mm) | 10Nos |
| Bore Gauge Range ( 0 – 250mm) | 3Nos |
| Slip Gauge (0.5mm – 100mm 0.01 step) | 1No |
